Amber PVC Strip Roll | Anti-Insect Yellow PVC Curtain Roll
₹6,189 ₹8,779
Insect-repelling yellow-amber PVC — keeps flies and flying insects out of food zones.
- ✨ Amber/yellow tint (590nm wavelength repels insects)
- 📏 Widths: 200mm / 300mm / 400mm
- 🏭 Best for — food processing, kitchens, dairies, FMCG units, bakeries.
- 🧾 HSN 3920 49 00 + GST invoice — ITC-claim valid for B2B buyers.
✅ Full specs, sizing chart & installation guide →
❓ Frequently Asked Questions
Are Chronovex insect catchers safe for food-handling areas?
Yes. Chronovex glue-pad insect catchers use no insecticide spray and no electrocution grid — they comply with FSSAI Schedule IV (Hygienic Practices) which specifies non-toxic pest control for food premises.
What is the difference between glue-pad and electric-grid insect killers?
Glue-pad units trap insects on a replaceable adhesive board (no "zap" debris, food-safe). Electric-grid units electrocute insects — effective for warehouses and outdoor sheds but not recommended directly above food prep.
How often should the glue pad be replaced?
Replace the glue pad every 30 days, or sooner if more than 60% of the surface is covered with trapped insects. Chronovex glue-pad refills are sold as spare-parts SKUs.
What is the coverage area of a single insect catcher?
Coverage depends on UV wattage. A 2x15W unit covers ~80 sq m, a 2x20W unit covers ~120 sq m. Mount at 2.0 to 2.5 m height, away from competing light sources.
Roll calculator — how many rolls for your doors
Price is per roll of 50 m. Enter your door sizes: we work out the metres of PVC strip with 50% overlap and the rolls you need.
Get a Callback / Quote on WhatsApp
Already purchased? Register your unit Get your warranty activated within 24 hrs — Hinglish helpline available.
Register Now SKU: 157-2 MM-NORMAL
Categories: All Products, PVC Curtains & Rolls, PVC Roll
Share:
Video dekhein
PVC strip curtain installation
Sliding PVC strip curtain
Hook-on hardware for PVC strip curtainsSaath mein ye bhi lagta hai
Air Curtain 3 Feet | Metal Body (Standard Series)Door khula rehta hai? Air curtain AC ki thandak andar rakhta hai₹13,749
Magnetic PVC Strip Curtain | Self-Closing Industrial Curtain | ChronovexAC room ke door ke liye self-closing magnetic parda₹9,570 (3x7 ft door)
Insect Killer 1 Feet (Bluster 12-PK) | ChronovexMakkhi-machchhar ke liye insect killer saath lagayein₹3,919Aapne haal hi mein dekha
Amber Anti-Insect Yellow PVC Strip Roll
Insect-repelling yellow-amber PVC — keeps flies and flying insects out of food zones. ISO 9001:2015 Noida • GST tax invoice • pan-India dispatch
📋 At a glance
- Amber/yellow tint (590nm wavelength repels insects)
- Widths: 200mm / 300mm / 400mm
- Thickness: 2mm / 3mm
- Roll length: 50m standard
- Temperature range: -5°C to +60°C
- Food-grade compliant compound
- Warranty: 6 months manufacturing defects (PVC material) / 12 months on hardware (steel rail + hooks)
- Compliance: RoHS, ISO 9001:2015 (Chronovex Noida QMS), food-grade compound where specified
- HSN code: 3920 49 00 — GST 18%
📖 Where this is used
Engineered for: dairy processing units, FMCG packaging halls, bakery production lines, restaurant kitchen entrances.
This amber anti-insect yellow PVC product is part of the Chronovex industrial PVC strip curtain range — used by FMCG plants, cold-storage facilities, automotive body shops, hospitals, restaurants, schools, banks, and SME retail across India. Each unit ships from Chronovex Noida factory with full GST invoice for ITC claim.
🔍 Why pick this from Chronovex?
- 🏭 Manufactured at our Noida factory — not re-branded imports. Quality control by ISO 9001:2015 certified QMS, with batch traceability for B2B audit.
- 📦 Same-day dispatch — stocked at Noida warehouse. Delhi NCR receives the same day and every other pincode (Mumbai, Bangalore, Chennai, Hyderabad, Pune, Ahmedabad, Kolkata and the rest of India) in 4–7 days via insured courier.
- 📄 Full GST tax invoice — HSN 3920 49 00, GST 18%. ITC-claim valid invoice with e-way bill auto-generated for shipments above ₹50,000.
- 🎓 Free pre-purchase consultation — our sales team helps you spec the right width, thickness, and overlap for your door size and traffic load. WhatsApp / email / phone support.
- 🔎 Bulk pricing — 5+ units bulk slab, 10+ units free pan-India shipping. AMC vendors and authorized resellers get dedicated pricing tier with 30–60 day terms (subject to credit approval).
- 🎯 Installation support — Paid on-site installation is available in Tier-1 cities. Free PDF installation guide included with every order.
❓ Frequently asked questions
How do I decide the sizing (width, thickness, overlap)?
You need to know the door width. Standard rule: strip width = 200mm for doors below 6ft, 300mm/400mm for wider doors. Thickness: 2mm general purpose, 3mm heavy-duty (fork-lift / loading), 4mm extreme heavy-duty. 50% strip overlap recommended for full air-seal (each strip overlaps the next by half its width). Our sales team will recommend the exact spec based on your door dimensions — just WhatsApp or email us.
Roll vs Complete Set — what is the difference?
The Roll is bulk material — you install it with your own hardware (hanger rail, hooks). The Complete Set is a ready-to-install kit — pre-cut strips + SS304 hanger rail + anti-rust hardware all come in one box for the specified door size. For a single door, take the Complete Set (more convenient). For multiple doors or custom dimensions, take the Roll + Hanger Hardware separately (more cost-effective).
How is it installed?
The hanger rail is mounted at the top of the door frame with a steel angle bracket / unistrut (4-6 M8 expansion bolts in concrete, or 4 self-tap screws in a steel frame). The PVC strips are then hung on the rail with hooks / M-clamps at 50% overlap. Time: 30–45 minutes for a 6ft door with a 2-person crew. A free PDF installation guide comes with every order. Professional installation is available in Tier-1 cities at ₹1,500–3,000 per door.
Kaunsa PVC variant choose karu?
Clear/Plain: general AC retention + dust barrier (warehouses, offices). Polar: cold rooms (flexible down to -25°C). Ribbed: fork-lift / loading bays (anti-scratch). Opaque: privacy + visual barrier (production lines). Amber: food zones (insect-repelling). Welding: fabrication shops (UV-filter, FR-grade). Magnetic: AC offices, clinics (zero-leak self-close). Tell our sales team your use case and they will recommend the exact match.
What is the warranty and how do I get a replacement?
6-month manufacturing defect warranty on the PVC material (cracks, tears, premature brittleness from a compound defect). 12-month rust/corrosion warranty on the steel hardware. Mechanical damage (fork-lift impact, cutting, abrasion from heavy traffic) is not covered — normal wear-and-tear is expected. To claim, courier the original invoice + a photo of the defect to Noida HQ. An approved claim's replacement is dispatched within 5–7 working days.
What are the bulk pricing and AMC vendor terms?
Bulk slab pricing on 5+ units, free pan-India shipping on 10+, and custom branding (your logo embossed on the hanger / packaging) on 25+ with a 3-week lead time. AMC vendors and authorised Chronovex resellers get a dedicated pricing tier with 30–60 day payment terms (subject to credit approval). Contact the sales team through the product page form for an actual bulk / vendor quote.
HSN code + GST invoice details?
HSN 3920 49 00 — GST 18%. Full tax invoice provided for ITC claim. E-way bill auto-generated for B2B GST-registered buyers on shipments above ₹50,000. 30-day payment terms available on approval for MSME-registered buyers. Service partners and AMC vendors get a separate vendor code for consolidated monthly billing.
Frequently Asked Questions
Find answers to common questions about this product
A standard 50-metre roll of Amber Anti-Insect PVC strip in 200 mm width covers approximately one 8-foot wide doorway at 2.4 metre height with 50% overlap (industry-standard sealing overlap) — roughly 10–12 strips. For a 3 metre × 3 metre doorway, plan on 2 rolls. We can pre-cut to your exact door dimensions on request — share door W × H on WhatsApp +91 9997778202.
NORMAL grade uses standard DEHP-free phthalate — fine for indoor temperate environments. DOP (di-octyl phthalate) is more flexible and suits humid / coastal sites where you need extra flex life. MIX-DOP is our engineered blend for cold-storage and arctic-grade applications — stays flexible to −25 °C. Indian factories in Mumbai / Chennai / Kerala typically order DOP. North-India factories order NORMAL. Cold-storage / dairy plants order MIX-DOP.
UV cutoff at 540 nm makes the curtain invisible to most flying insects — flies & mosquitoes do not navigate to it, reducing entry by 80–90%. FSSAI-recommended for food-processing entries. Compared to standard industrial PVC, the Amber Anti-Insect grade adds a specific functional property that justifies a 15–25% price premium for sites that need it. If you do not need this property, our standard Clear Transparent grade is more economical.
Typical payback for Amber Anti-Insect PVC strip curtains is 4 months in conditioned-air environments. The curtain blocks 80–85% of air loss through an open doorway; for a 1500–3000 sqft HVAC-conditioned area at ₹12/sqft/month conditioning cost, the roll pays for itself in 4 months. Add hygiene savings (FSSAI / pest-control audit) and payback often falls below 4 months.
HSN 3920 49 (Other plates / sheets / film of PVC, non-cellular, not reinforced or combined with other materials), GST 18%. Every Chronovex B2B invoice carries IRN (Invoice Reference Number) and a signed QR code per CBIC e-invoicing rules — fully GSTR-2B eligible for input tax credit. PAN, GSTIN and HSN print on the invoice; delivery challan generated under Section 31 of the CGST Act. We are ISO 9001:2015 certified.
Standard delivery: same day in Delhi NCR, 4–7 days to every other pincode. For bulk pallet orders (10+ rolls), we offer 8–18% discount slabs and direct factory dispatch from Noida. Cut-to-size service is included for orders of 5+ rolls. WhatsApp +91 9997778202 with your door dimensions for a quote.
