Big Ring PVC Sheet Curtain 54" | Industrial Strip Door Curtain | Chronovex

Big Ring PVC Sheet Curtain 54" | Industrial Strip Door Curtain | Chronovex

Name: Big Ring PVC Sheet Curtain 54" | Industrial Strip Door Curtain | Chronovex
Brand: Chronovex Industries Private Limited
SKU: big-ring-pvc-sheet-curtain-54
Price: 196 INR
Availability: InStock

Brand: Chronovex Industries Private Limited

₹196.00 ₹231.00

Heavy-duty Big Ring PVC Sheet Curtain 54" wide ready-to-install kit — 6 thickness x 5 height combinations (6ft-10ft, 0.15mm-0.50mm). Big-bore SS hangers (50mm ring), industrial grade transparent strips, ideal for warehouse, loading bay, cold room, factory entrance.

Width: 54 inch standard strip
Heights: 6ft / 7ft / 8ft / 9ft / 10ft
Thickness: 0.15 / 0.20 / 0.25 / 0.30 / 0.40 / 0.50 mm
Ring Type: Big Ring SS304 (50mm bore, heavy-duty)
Warranty: 2 year manufacturing

❓ Frequently Asked Questions

Are Chronovex PVC strip curtains food-grade?

Yes — the standard rolls comply with BIS IS 10146 (specification for PVC in contact with foodstuffs). Polar-grade rolls for cold storage are dosed for flexibility at −25°C.

What thickness should I order for cold storage vs. a loading dock?

For freezer rooms (−18°C and below) use 3 mm polar-grade strips with 50% overlap. For chiller rooms (0°C to 8°C) use 2 mm standard. For warehouse dock doors with forklift traffic use 3 mm or 4 mm ribbed strips.

How long does a PVC strip curtain last?

Standard-grade strips last 3 to 5 years in normal indoor traffic. Polar-grade lasts 2 to 3 years in deep-freeze. Ribbed dock-grade lasts 18 to 24 months under forklift impact.

Do I need a separate hookon system to install the curtain?

Yes — stainless-steel hookon plates are sold separately. One plate per strip; pre-drilled for M6 hardware. Chronovex bundles a recommended hookon SKU with every roll size.

Already purchased? Register your unit Get your warranty activated within 24 hrs — Hinglish helpline available.

SKU:big-ring-pvc-sheet-curtain-54

Categories:All Products, PVC Curtains & Rolls, PVC Strip Curtain

Description

Big Ring PVC Sheet Curtain 54" — Complete Price Matrix

Chronovex Big Ring PVC Sheet Curtain bada-ring (50mm bore) hanger ke saath aata hai, jo wide door openings, warehouses, loading docks, cold storage entries aur high-traffic industrial doorways ke liye optimised hai. Heavy SS304 hanger system + 54" wide transparent strips combination zero air leakage aur fast self-close ensure karta hai.

Why Big Ring (50mm) vs Small Ring (25mm)?

Wide door openings (8ft+) ke liye preferred
Heavy industrial use — forklift traffic, frequent open/close
Easy strip replacement / swap (bigger bore = less wear)
SS304 build — corrosion resistant for humid/cold environments

Complete Price Matrix (Per Strip, incl. 18% GST) — 30 SKUs Listed

All prices are per individual strip 54" wide. Average door needs 8-12 strips depending on opening width. Ready-cut + ring + SS304 hanger included.

Height Thickness	0.15 mm	0.20 mm	0.25 mm	0.30 mm	0.40 mm	0.50 mm
6 Ft	₹231	₹259	₹301	₹329	₹413	₹469
7 Ft	₹252	₹287	₹336	₹364	₹462	₹532
8 Ft	₹280	₹315	₹371	₹406	₹518	₹588
9 Ft	₹301	₹343	₹406	₹448	₹567	₹644
10 Ft	₹322	₹371	₹434	₹476	₹616	₹714

Quick Reference — Bulk Discount Slabs

10-24 strips: 5% additional discount
25-49 strips: 10% additional discount + free pan-India shipping
50-99 strips: 12% additional discount + free hanger upgrade
100+ strips: 15% additional discount + project pricing + custom branding

Key Features

Premium Quality crystal-clear PVC, food-grade plasticiser
Durable & Long-lasting — minimum 24 months service life
Temperature Resistant: -25°C to +60°C operating range
Easy to Clean & Maintain — wipe-clean, no chemical cleaners needed
Ideal for Industrial & Commercial Use
SS304 Big Ring (50mm bore) included — corrosion resistant

Recommended Applications

Warehouse entries (wide doorways 8ft+)
Cold storage / freezer room entries
Loading docks aur forklift bays
Food processing aur dairy plants
Pharma clean rooms (entry barriers)
Automotive workshop entrances

Installation Kit Includes

Pre-cut transparent PVC strips (qty as ordered)
SS304 Big Ring hangers (50mm bore) — 1 per strip
Wall-mount header rail (sold separately on request)
Installation manual + measurement template

Mere door ke liye kitne strips chahiye?

Average rule: door width (inch) / 9 = strip count for 50% overlap (industry standard). Example: 60" wide door = 7 strips, 96" wide door = 11 strips. Sales team se exact measurement share karo, free calculation kar denge.

Konsi thickness mere use case ke liye sahi?

0.15-0.20mm light commercial doors (shops, offices). 0.25-0.30mm warehouse / cold storage entry. 0.40-0.50mm heavy freezer (-25°C) + forklift traffic doors.

Installation kaise hoti hai?

Wall pe header rail mount karke uspe Big Ring hanger se strips latkani hoti hain. DIY-friendly hai, 1 person 6ft door 30 min mein install kar sakta hai. AMC vendors ko installation video + on-call support free.

Bulk pricing aur AMC vendor terms?

10+ strips par tiered discount. AMC vendors + authorized resellers ke liye 30-60 day payment terms (credit approval subject to). Sales team se contact karo through product page form for actual quote.

HSN code + GST invoice?

HSN 3920 49 00 — GST 18%. Full tax invoice for ITC claim. B2B GST registered buyers ke liye e-way bill auto-generated for shipments above ₹50,000.
