Air Curtain 3 Feet | Metal Body (Advanced Series)
₹23,649 ₹38,769
3 Feet (0.9 m) metal-body air curtain for factories, warehouses, loading bays, cold rooms. Single-phase 220 V, 200 W 2× industrial-duty Indian copper motors with thermal cut-off, 1,500 CFM peak airflow — Industrial-grade barrier for 3ft retail, pharmacy and showroom entrances.
- 💨 1,500 CFM high · 1,100 CFM low · jet reach ~3.2 m
- ⚡ 200 W · 220 V single-phase · 2 motors / 3 blowers
- 🛡️ Metal body · ≤65 dB · ~13.5 kg · HSN 8414 59 10
- 📍 ISO 9001:2015 Noida · 5-year warranty · pan-India dispatch
📖 Read full specs, install guide & buyer FAQ ↓
❓ Frequently Asked Questions
Get a Callback / Quote on WhatsApp
- Warranty: 5 years parts + 1 year service (compare series)
- Service: onsite warranty service, Hinglish helpline
- Spares: genuine air curtain spare parts
- Returns: 3-day return & refund policy
SKU: PCX-3-FEET-A-200 WATTS-2 MOTOR 3 BLOWERS-1500 CFM (H), 1100 CFM (L)-220 V; SINGLE PHASE, 50 HZ-3 FEET-ADVANCED
Categories: Metal Body Air Curtains
Standard vs Premium vs Advanced — what actually differs
For a given size, all three deliver the same airflow, wattage and CFM. The difference is not the specification — it is the grade of the components behind it. A 100% copper motor can be sourced at very different price points; the rating stays the same while life, durability and support do not. That grade is what separates these three series, and the onsite warranty reflects it.
| Standard | Premium | Advanced | |
|---|---|---|---|
| Best suited for | Shops, offices, showrooms | Hotels, malls, hospitals | Factories, warehouses, cold storage |
| Duty cycle | Regular daily use | Extended daily operation | 24×7 continuous |
| Motor grade | Entry-grade 100% copper | Higher-grade 100% copper | Industrial premium-grade |
| Expected service life | 3–5 years | 8–10 years | 15–20 years |
| Onsite warranty | 1 year | 3 years | 5 years |
| Airflow / wattage / CFM | Same | Same | Same |
Body gauge and bearing type are common across the range; the difference lies in component quality and sourcing.
Is the 3 ft Metal Advanced air curtain right for your door?
This model covers doors wider than 2 ft and up to 3 ft wide. The air curtain should be at least as long as the door opening, so the air stream covers the full width. It is typically used on standard single doors: small shops, offices, clinics, pharmacies and restaurant kitchen doors. If your door is wider than 3 ft, choose the 1 m (3.3 ft) model. Doors wider than 7 ft use two or more units side by side; the door size price finder works out the exact combination.
The powder-coated metal body is sturdy and economical, suited to shops, offices and general commercial doors. Price for this model: ₹23,649, GST and installation included. The final quote is confirmed on WhatsApp after we see a photo of your door.
Metal Advanced series: all sizes
| Size | Door width | Price (GST + installation) |
|---|---|---|
| 2 ft | up to 2 ft | ₹23,099 |
| 3 ft (this model) | > 2 ft to 3 ft | ₹23,649 |
| 1 m (3.3 ft) | > 3 ft to 1 m (3.3 ft) | ₹24,199 |
| 4 ft | > 1 m (3.3 ft) to 4 ft | ₹25,849 |
| 5 ft | > 4 ft to 5 ft | ₹29,699 |
| 6 ft | > 5 ft to 6 ft | ₹31,349 |
| 7 ft | > 6 ft to 7 ft | ₹34,649 |
Other 3 ft options
- 3 ft Metal Standard – ₹13,749
- 3 ft Aluminium Standard – ₹16,499
- 3 ft Metal Premium – ₹18,689
- 3 ft Aluminium Premium – ₹21,439
- 3 ft SS304 Standard – ₹23,539
- 3 ft Aluminium Advanced – ₹26,949
Quick answers for the 3 ft model
Which door width does a 3 ft air curtain suit?
Doors wider than 2 ft and up to 3 ft wide. For a wider door, go to 1 m (3.3 ft).
Is installation included in the ₹23,649 price?
Yes. The price includes GST and standard installation. Send your door photo on WhatsApp to confirm the final quote.
When should I choose the Metal body?
The powder-coated metal body is sturdy and economical, suited to shops, offices and general commercial doors. For food, pharma or wet areas, see the 3 ft SS304 Standard (₹23,539).
Prices live from our catalogue, GST-inclusive. Final quote is confirmed on WhatsApp after a door photo.
Product videos
Air curtain installation - step by step
Benefits of an air curtain
Chronovex air curtains, insect killers and PVC curtainsFrequently bought together
Magnetic PVC Strip Curtain | Self-Closing Industrial Curtain | ChronovexSelf-closing magnetic PVC curtain for AC room doors₹9,570 (3x7 ft door)
Insect Killer 1 Feet (Bluster 12-PK) | ChronovexAdd an insect killer to stop flies and mosquitoes₹3,919
Plain PVC Strip Curtain (Complete Set) | Industrial PVC Door Curtain | ChronovexPVC strip curtain for cold room and warehouse doors₹5,103 (3x7 ft door)Recently viewed
The 3 ft Metal Advanced air curtain is built for doors up to 3 ft (0.9 m) wide. 2 Indian copper motors and 3 cross-flow blowers deliver 1,500 CFM at up to 23 m/s on 200 W, enough to seal the full opening against hot air, dust and flies. The powder-coated metal body is sturdy and suits shops, offices and general commercial doors.
3 ft Metal Advanced at a glance
| Door width | up to 3 ft (0.9 m) |
| Model no. | PCX090 |
| Dimensions | 900 × 210 × 225 mm |
| Motors / blowers | 2 Indian copper motors and 3 cross-flow blowers |
| Power | 200 W |
| Airflow (High / Low) | 1,500 / 1,100 CFM |
| Air velocity | up to 23 m/s |
| Noise | 50 dB |
| Mount height | 2.2 – 2.7 m |
| Body | Powder-coated steel |
| Weight | 15 kg |
| Supply | 220 V · single-phase · 50 Hz |
| HSN | 8414 59 10 |
Where the 3 ft model is used
Small shops, clinics, chemist counters, offices and restaurant kitchen doors.
3 ft vs the sizes next to it (Metal Advanced)
| 2 ft | 3 ft (this model) | 1 m | |
|---|---|---|---|
| Door width | up to 2 ft | up to 3 ft | up to 1 m |
| Airflow | 1,000 CFM | 1,500 CFM | 1,500 CFM |
| Motors / blowers | 1 / 2 | 2 / 3 | 2 / 3 |
| Power | 120 W | 200 W | 200 W |
Included with the Metal Advanced series
Powder-coated steel body; Indian copper motors; mounting kit and user manual; warranty: 5 years replacement on motor + blower assembly; GST tax invoice with ITC eligibility; dispatch: 3–5 working days (pan-India surface freight). Volume pricing on 10+ units.
3 ft air curtain: common questions
Will a 3 ft air curtain cover a 3 ft door?
Yes. It matches the door width, and the 1,500 CFM stream covers the full opening when mounted at 2.2 – 2.7 m.
How much power does the 3 ft Metal Advanced use?
200 W on High speed, on a 220 V · single-phase · 50 Hz supply.
My door is a little wider than 3 ft. What should I choose?
Go one size up to the 1 m Metal Advanced (1,500 CFM).
