Air Curtain 6 Feet | Metal Body (Advanced Series)
₹31,349 ₹44,469
6 Feet (1.8 m) aluminium-body air curtain for factories, warehouses, loading bays, cold rooms. Single-phase 220 V, 360 W 3× industrial-duty Indian copper motors with thermal cut-off, 3,000 CFM peak airflow — Heavy-duty industrial barrier for 6ft factory, godown and chiller entrances.
- 💨 3,000 CFM high · 2,250 CFM low · jet reach ~3.6 m
- ⚡ 360 W · 220 V single-phase · 3 motors / 6 blowers
- 🛡️ Aluminium body · ≤66 dB · ~24.5 kg · HSN 8414 59 10
- 📍 ISO 9001:2015 Noida · 5-year warranty · pan-India dispatch
📖 Read full specs, install guide & buyer FAQ ↓
❓ Frequently Asked Questions
Get a Callback / Quote on WhatsApp
- Warranty: 5 years parts + 1 year service (compare series)
- Service: onsite warranty service, Hinglish helpline
- Spares: genuine air curtain spare parts
- Returns: 3-day return & refund policy
SKU: PCX-6-feet-A-360 WATTS-3 MOTOR 6 BLOWERS-3000 CFM (H), 2250 CFM (L)-220 V; SINGLE PHASE, 50 HZ-ADVANCED
Categories: Metal Body Air Curtains
Standard vs Premium vs Advanced — what actually differs
For a given size, all three deliver the same airflow, wattage and CFM. The difference is not the specification — it is the grade of the components behind it. A 100% copper motor can be sourced at very different price points; the rating stays the same while life, durability and support do not. That grade is what separates these three series, and the onsite warranty reflects it.
| Standard | Premium | Advanced | |
|---|---|---|---|
| Best suited for | Shops, offices, showrooms | Hotels, malls, hospitals | Factories, warehouses, cold storage |
| Duty cycle | Regular daily use | Extended daily operation | 24×7 continuous |
| Motor grade | Entry-grade 100% copper | Higher-grade 100% copper | Industrial premium-grade |
| Expected service life | 3–5 years | 8–10 years | 15–20 years |
| Onsite warranty | 1 year | 3 years | 5 years |
| Airflow / wattage / CFM | Same | Same | Same |
Body gauge and bearing type are common across the range; the difference lies in component quality and sourcing.
🔍 At a Glance
6 Feet • 360W • 3 motors • 3,000 CFM • 66 dB • 1.0mm steel • heater-ready
⚙️ Specifications
| Door width | 6 Feet (1.8 m) | Mount height | 2.4 – 3.1 m |
| Motor power | 360 W (3× industrial copper motors with thermal cut-off + sealed bearings) | Blowers | 6 cross-flow |
| Airflow (High) | 3,000 CFM | Airflow (Low) | 2,250 CFM |
| Air velocity | 13 – 17 m/s | Voltage | 220 V · single-phase · 50 Hz |
| Body | Powder-coated aluminium | Noise | ≤66 dB |
| Weight | ~24.5 kg | HSN | 8414 59 10 |
✨ Key Features
- 🏭 1.0mm powder-coat steel body — 25% thicker than Premium, dent-resistant, factory-grade powder coat finish for dust and oil environments.
- ⚡ 360W industrial copper motor stack — 3× sealed-bearing Indian copper motors with thermal cut-off, built for 12-hour duty cycles.
- 💨 3,000 CFM @ 17 m/s jet — industrial-grade airflow that holds the seal even when doors are open longer and traffic is heavy.
- 🔥 Heater-coil ready terminals — pre-wired for optional heated-curtain upgrade in cold-room or winter-North-India deployments. No rewiring needed.
- 📡 IR sensor + RF remote — auto-trigger on door open, manual override via remote. Two-speed (Low/High) for shift-pattern usage.
- 🛡️ 5-year motor warranty — industry-leading coverage from Chronovex Noida, with pan-India service and Indian copper spares availability.
📦 In the Box
- 1 × Air Curtain 6ft Aluminium Metal Body Advanced Series
- Mounting bracket kit + screws + wall plugs
- User manual + warranty card
- Chronovex GST invoice (B2B claim eligible)
📍 Who Should Buy This?
- 🏭 Factory & plant gates — personnel and small-vehicle entrances where the door stays open during shift changes and material movement.
- 🚚 Warehouse loading bays — forklift and dock-door openings where dust, fumes and pest ingress need to be sealed off without slowing operations.
- ❄️ Cold rooms & chillers — pair with heater-ready terminals later, or use as-is to reduce condensation and energy loss at chiller entrances.
- 🍳 Commercial kitchens & food processing — keep flies, dust and odour out of prep areas while staff move freely between hot and cold zones.
- 🏥 Hospital service entrances — ambulance bays, mortuary access, supply doors where pest and contaminant ingress must be controlled 24×7.
- 🏫 Auditoriums & banquet halls — large-format public entrances with heavy footfall, where Premium quietness is less critical than barrier strength.
🛠️ Installation Notes
- Mount horizontally above the door frame, height 2.4–3.1 m (lower = stronger barrier).
- Air jet should point slightly outward (5–10°) to deflect incoming flies/dust.
- Plug into a dedicated 5 A / 220 V outlet — no rewiring needed.
- Test high mode first (3,000 CFM), then low mode for off-peak hours.
- Clean filter grille every 30 days (dust load varies by location).
❓ Quick FAQ
Q. Is a heater coil included?
The heater coil is not pre-installed, but heater-ready terminals are factory-wired. You can add the heated-curtain kit later without rewiring. Mention it at the time of order and it will be factory-fitted.
Q. How many hours a day can it run?
It has an industrial duty rating — 12 hours continuous, safely, with a thermal cut-off protecting the motors during overload. For 24/7 use, rotating 2 units is recommended.
Q. Premium vs Advanced — kaunsa lu?
Showroom, clinic, mall, hotel — take the Premium. Factory gate, warehouse, cold room, loading bay — take the Advanced. The Advanced gives thicker steel + heater-ready terminals + a 5-yr warranty.
Q. What is the installation height?
2.4m to 3.1m mounting range. It is installed at the top of the door with a steel angle bracket. An installation guide PDF comes with the order.
Q. Will I get a GST invoice?
Yes, a full GST tax invoice with HSN 8414 59 10 — valid for ITC claim. Pan-India shipping with insured transit.
📊 Compare — Metal Body Advanced 6 Feet vs Premium vs Standard
| Specification | Metal Advanced | Metal Premium | Metal Standard |
|---|---|---|---|
| Body thickness | 1.0mm powder-coat steel | 0.8mm powder-coat steel | 0.6mm steel |
| Motor warranty | 5 years | 3 years | 1 year |
| Heater-ready | Yes (pre-wired) | No | No |
| IR + remote | Yes | Yes | Manual switch |
| Bearings | Sealed industrial | Standard sealed | Standard |
| Best for | Factories, cold rooms, loading bays | Showrooms, clinics, malls | Shops, offices, small retail |
| 6 Feet airflow | 3,000 CFM | 3,000 CFM | ~2,250 CFM |
| Noise level | 66 dB | 64 dB (quieter) | 68 dB |
🛡️ Why Chronovex?
- ISO 9001:2015 certified manufacturing — Noida, U.P.
- 5-year replacement warranty on motor + blower assembly.
- Pan-India dispatch — same day from Noida; delivery 4–7 days (Delhi NCR same day).
- GST invoice — full ITC claim eligible for B2B buyers.
- Direct factory support — no dealer markup, WhatsApp +91 9997778202.
📖 Product Overview & Buyer Guide
The 6 Feet Metal Body Advanced air curtain is engineered for the toughest Indian commercial and light-industrial conditions. With a 360W industrial copper motor stack pushing 3,000 CFM through a thicker 1.0mm powder-coated steel housing, this unit handles factory gates, warehouse loading bays, cold-room entrances, large kitchen pass-throughs and food-processing plants where Aluminium or Standard Metal bodies wear out. Heater-coil ready terminals, IR sensor, remote, sealed bearings, thermal cut-off, and a 5-year motor warranty make this the unit Chronovex specifies when downtime is not an option.
🏅 Manufacturing & Quality
Chronovex Industries Pvt. Ltd. manufactures every air curtain at our ISO 9001:2015 certified facility in Noida, Uttar Pradesh. Each 6ft Aluminium Metal Body Advanced unit passes 12 QC checkpoints — motor balancing, blower alignment, voltage stability (200–240 V tolerance), thermal cut-off testing, noise level (≤66 dB at 1 m), and a full 30-minute run-test before packaging.
⚙️ Why specify Metal Body Advanced over Premium or Standard?
Premium Metal Body is sized for showrooms, clinics and clean retail — 0.8mm steel, IR + remote, quiet operation. Advanced is built for the next tier up: factory gates, loading bays, cold rooms and busy commercial kitchens where doors stay open longer, dust load is higher, and a failed unit means production loss. You get 1.0mm steel (25% thicker shell, better dent resistance), industrial copper motors with sealed bearings, heater-coil terminals pre-wired so you can add a heated curtain later without rewiring, and a 5-year motor warranty (vs 3-yr on Premium). If your site has fork-lift traffic, conveyor lines, or a cold-room chiller behind the door, Advanced is the right specification.
🚚 Logistics, Warranty & Support
| Lead time | 3–5 working days (pan-India surface freight) |
| Packaging | Double-wall corrugated carton + EPE foam, transit-rated |
| Warranty | 5 years replacement on motor + blower assembly |
| Invoice | GST tax invoice with full ITC eligibility |
| Bulk pricing | Volume discount on 10+ units (contact for B2B rate card) |
