Opaque PVC Strip Roll | Industrial Privacy PVC Curtain Roll

Brand: Chronovex Industries Private Limited

₹6,189 ₹8,779

Privacy-grade opaque white roll — visual barrier + air-seal for production lines.

✨ Opaque white (light blocking)
📏 Widths: 200mm / 300mm / 400mm
🏭 Best for — production lines, paint booths, partitioned bays, office zones.
🧾 HSN 3920 49 00 + GST invoice — ITC-claim valid for B2B buyers.

✅ Full specs, sizing chart & installation guide →

❓ Frequently Asked Questions

Are Chronovex PVC strip curtains food-grade?

Yes — the standard rolls comply with BIS IS 10146 (specification for PVC in contact with foodstuffs). Polar-grade rolls for cold storage are dosed for flexibility at −25°C.

What thickness should I order for cold storage vs. a loading dock?

For freezer rooms (−18°C and below) use 3 mm polar-grade strips with 50% overlap. For chiller rooms (0°C to 8°C) use 2 mm standard. For warehouse dock doors with forklift traffic use 3 mm or 4 mm ribbed strips.

How long does a PVC strip curtain last?

Standard-grade strips last 3 to 5 years in normal indoor traffic. Polar-grade lasts 2 to 3 years in deep-freeze. Ribbed dock-grade lasts 18 to 24 months under forklift impact.

Do I need a separate hookon system to install the curtain?

Yes — stainless-steel hookon plates are sold separately. One plate per strip; pre-drilled for M6 hardware. Chronovex bundles a recommended hookon SKU with every roll size.

Roll calculator — how many rolls for your doors

Price is per roll of 50 m. Enter your door sizes: we work out the metres of PVC strip with 50% overlap and the rolls you need.

Get a Callback / Quote on WhatsApp

Already purchased? Register your unit Get your warranty activated within 24 hrs — Hinglish helpline available.

SKU: 156-2 MM-NORMAL

Categories: All Products, PVC Curtains & Rolls, PVC Roll

Description
Questions and Answers

Opaque PVC Strip Roll

Privacy-grade opaque white roll — visual barrier + air-seal for production lines. ISO 9001:2015 Noida • GST tax invoice • pan-India dispatch

📋 At a glance

Opaque white (light blocking)
Widths: 200mm / 300mm / 400mm
Thickness: 2mm / 3mm
Roll length: 50m standard
Temperature range: -5°C to +60°C
Reduces visual distractions on production line
Warranty: 6 months manufacturing defects (PVC material) / 12 months on hardware (steel rail + hooks)
Compliance: RoHS, ISO 9001:2015 (Chronovex Noida QMS), food-grade compound where specified
HSN code: 3920 49 00 — GST 18%

📖 Where this is used

Engineered for: production line separators, paint booth doors, office-to-floor barriers, visual privacy zones.

This opaque white privacy PVC product is part of the Chronovex industrial PVC strip curtain range — used by FMCG plants, cold-storage facilities, automotive body shops, hospitals, restaurants, schools, banks, and SME retail across India. Each unit ships from Chronovex Noida factory with full GST invoice for ITC claim.

🔍 Why pick this from Chronovex?

🏭 Manufactured at our Noida factory — not re-branded imports. Quality control by ISO 9001:2015 certified QMS, with batch traceability for B2B audit.
📦 Same-day dispatch — stocked at Noida warehouse. Delhi NCR receives the same day and every other pincode (Mumbai, Bangalore, Chennai, Hyderabad, Pune, Ahmedabad, Kolkata and the rest of India) in 4–7 days via insured courier.
📄 Full GST tax invoice — HSN 3920 49 00, GST 18%. ITC-claim valid invoice with e-way bill auto-generated for shipments above ₹50,000.
🎓 Free pre-purchase consultation — our sales team helps you spec the right width, thickness, and overlap for your door size and traffic load. WhatsApp / email / phone support.
🔎 Bulk pricing — 5+ units bulk slab, 10+ units free pan-India shipping. AMC vendors and authorized resellers get dedicated pricing tier with 30–60 day terms (subject to credit approval).
🎯 Installation support — Paid on-site installation is available in Tier-1 cities. Free PDF installation guide included with every order.

❓ Frequently asked questions

How do I decide the sizing (width, thickness, overlap)?

You need to know the door width. Standard rule: strip width = 200mm for doors below 6ft, 300mm/400mm for wider doors. Thickness: 2mm general purpose, 3mm heavy-duty (fork-lift / loading), 4mm extreme heavy-duty. 50% strip overlap recommended for full air-seal (each strip overlaps the next by half its width). Our sales team will recommend the exact spec based on your door dimensions — just WhatsApp or email us.

Roll vs Complete Set — what is the difference?

The Roll is bulk material — you install it with your own hardware (hanger rail, hooks). The Complete Set is a ready-to-install kit — pre-cut strips + SS304 hanger rail + anti-rust hardware all come in one box for the specified door size. For a single door, take the Complete Set (more convenient). For multiple doors or custom dimensions, take the Roll + Hanger Hardware separately (more cost-effective).

How is it installed?

The hanger rail is mounted at the top of the door frame with a steel angle bracket / unistrut (4-6 M8 expansion bolts in concrete, or 4 self-tap screws in a steel frame). The PVC strips are then hung on the rail with hooks / M-clamps at 50% overlap. Time: 30–45 minutes for a 6ft door with a 2-person crew. A free PDF installation guide comes with every order. Professional installation is available in Tier-1 cities at ₹1,500–3,000 per door.

Kaunsa PVC variant choose karu?

Clear/Plain: general AC retention + dust barrier (warehouses, offices). Polar: cold rooms (flexible down to -25°C). Ribbed: fork-lift / loading bays (anti-scratch). Opaque: privacy + visual barrier (production lines). Amber: food zones (insect-repelling). Welding: fabrication shops (UV-filter, FR-grade). Magnetic: AC offices, clinics (zero-leak self-close). Tell our sales team your use case and they will recommend the exact match.

What is the warranty and how do I get a replacement?

6-month manufacturing defect warranty on the PVC material (cracks, tears, premature brittleness from a compound defect). 12-month rust/corrosion warranty on the steel hardware. Mechanical damage (fork-lift impact, cutting, abrasion from heavy traffic) is not covered — normal wear-and-tear is expected. To claim, courier the original invoice + a photo of the defect to Noida HQ. An approved claim's replacement is dispatched within 5–7 working days.

What are the bulk pricing and AMC vendor terms?

Bulk slab pricing on 5+ units, free pan-India shipping on 10+, and custom branding (your logo embossed on the hanger / packaging) on 25+ with a 3-week lead time. AMC vendors and authorised Chronovex resellers get a dedicated pricing tier with 30–60 day payment terms (subject to credit approval). Contact the sales team through the product page form for an actual bulk / vendor quote.

HSN code + GST invoice details?

HSN 3920 49 00 — GST 18%. Full tax invoice provided for ITC claim. E-way bill auto-generated for B2B GST-registered buyers on shipments above ₹50,000. 30-day payment terms available on approval for MSME-registered buyers. Service partners and AMC vendors get a separate vendor code for consolidated monthly billing.

Frequently Asked Questions

Find answers to common questions about this product

A standard 50-metre roll of Opaque Privacy PVC strip in 200 mm width covers approximately one 8-foot wide doorway at 2.4 metre height with 50% overlap (industry-standard sealing overlap) — roughly 10–12 strips. For a 3 metre × 3 metre doorway, plan on 2 rolls. We can pre-cut to your exact door dimensions on request — share door W × H on WhatsApp +91 9997778202.

NORMAL grade uses standard DEHP-free phthalate — fine for indoor temperate environments. DOP (di-octyl phthalate) is more flexible and suits humid / coastal sites where you need extra flex life. MIX-DOP is our engineered blend for cold-storage and arctic-grade applications — stays flexible to −25 °C. Indian factories in Mumbai / Chennai / Kerala typically order DOP. North-India factories order NORMAL. Cold-storage / dairy plants order MIX-DOP.

Solid opaque grade blocks visual line-of-sight while still allowing easy walk-through and air-curtain pairing. Compared to standard industrial PVC, the Opaque Privacy grade adds a specific functional property that justifies a 15–25% price premium for sites that need it. If you do not need this property, our standard Clear Transparent grade is more economical.

Typical payback for Opaque Privacy PVC strip curtains is 5 months in conditioned-air environments. The curtain blocks 80–85% of air loss through an open doorway; for a 1500–3000 sqft HVAC-conditioned area at ₹12/sqft/month conditioning cost, the roll pays for itself in 5 months. Add hygiene savings (FSSAI / pest-control audit) and payback often falls below 5 months.

HSN 3920 49 (Other plates / sheets / film of PVC, non-cellular, not reinforced or combined with other materials), GST 18%. Every Chronovex B2B invoice carries IRN (Invoice Reference Number) and a signed QR code per CBIC e-invoicing rules — fully GSTR-2B eligible for input tax credit. PAN, GSTIN and HSN print on the invoice; delivery challan generated under Section 31 of the CGST Act. We are ISO 9001:2015 certified.

Standard delivery: same day in Delhi NCR, 4–7 days to every other pincode. For bulk pallet orders (10+ rolls), we offer 8–18% discount slabs and direct factory dispatch from Noida. Cut-to-size service is included for orders of 5+ rolls. WhatsApp +91 9997778202 with your door dimensions for a quote.
