Air Curtain 4 Feet | Aluminium Body (Standard Series)

Features

Heavy-duty aluminium body air curtain for commercial use
High air velocity output for effective door sealing
Optimized 4 feet air curtain for wider entrances
Energy-efficient motor for long operating hours
Low-noise operation suitable for customer-facing areas
Wall-mounted design with sturdy mounting brackets
Corrosion-resistant powder-coated finish
Designed for Indian voltage and climate conditions

Applications

Supermarkets and retail outlets
Restaurants, cafés, and food courts
Pharmacies and hospitals
Office buildings and commercial complexes
Warehouses and logistics entry points
Hotels, salons, and showrooms

Benefits

Prevents insects, dust, smoke, and outside pollution
Minimizes air-conditioning loss and reduces electricity bills
Maintains indoor temperature and comfort
Improves hygiene compliance for commercial spaces
Enhances customer experience at entry points
Reliable and cost-effective solution for medium doorways

Detailed Product Description

The Chronovex Standard Series 4 Feet Air Curtain creates a powerful and uniform air barrier across door openings, preventing external contaminants from entering conditioned spaces. Its lightweight yet strong aluminium housing ensures durability, while the industrial-grade motor delivers consistent air flow with optimized power consumption.

This model is ideal for businesses seeking a balance between performance, durability, and affordability for wider commercial entrances.

Technical Specifications

Parameter	Details
Product Type	Air Curtain
Series	Standard Series
Length	4 Feet
Body Material	Aluminium
Mounting	Wall-mounted (Above Door)
Air Velocity	High-speed uniform air flow
Noise Level	Low
Power Supply	220–240V AC, 50 Hz
Operation	Continuous Duty
Finish	Powder Coated
Application Area	Commercial / Light Industrial

Comparison Table

Feature	Standard Series	Premium Series	Advanced Series
Body Material	Aluminium	Aluminium	Aluminium
Motor Type	Standard Industrial	Premium Copper Motor	Industrial Premium (100% Copper)
Energy Efficiency	Good	Better	Best
Sensor Included	No	No	Yes (Free)
Warranty	1 Year Service	3 Years Parts	5 Years Parts
Recommended Usage	Shops & Offices	Commercial	Heavy-Duty / 24×7

Installation & Maintenance

Installation Overview

Installed above the door opening
Suitable for medium-width entrances
Requires standard single-phase power supply

Maintenance Guidelines

Periodic cleaning of air inlet grills
Check mounting bolts and electrical connections
Ensure outlet remains obstruction-free

Step-by-Step Installation Guide

Measure door width and confirm 4 feet compatibility
Mark and drill holes for mounting brackets
Secure brackets firmly to the wall
Mount the air curtain unit on brackets
Align horizontally for uniform air flow
Connect power supply through certified electrician
Test operation and air velocity

Certifications & Compliance

ISO-certified manufacturing facility
Compliant with Indian electrical safety standards
Suitable for commercial hygiene and safety norms

Regional Availability & Support

PAN-India Installation Network

PAN India delivery coverage
Installation support via authorized partners
Dedicated service and support team

FAQs

Q1. Is a 4 feet air curtain suitable for supermarkets?
Yes, it is ideal for medium-width entrances commonly found in supermarkets.

Q2. Can this air curtain run all day?
Yes, it is designed for continuous commercial operation.

Q3. Does it help reduce AC power consumption?
Yes, it significantly reduces cold air leakage, improving energy efficiency.

Q4. Is installation support available across India?
Yes, PAN India installation assistance is available.

SEO Meta Data

Meta Title:
Air Curtain 4 Feet Aluminium Body | Standard Series – Chronovex

Meta Description:
Buy 4 feet aluminium air curtain for shops, supermarkets & offices. Energy-efficient, durable, PAN India delivery. Chronovex Standard Series.

Focus Keywords:
4 feet air curtain, aluminium air curtain, air curtain for supermarket, commercial air curtain India, standard series air curtain

Why Choose Chronovex Industries Pvt. Ltd.?

Chronovex Industries Pvt. Ltd. is an ISO-certified Indian manufacturer and supplier of industrial hygiene and climate control solutions, serving customers across PAN India.

Why industries trust Chronovex:

ISO-certified manufacturing standards
Heavy-duty industrial-grade products
Energy-efficient and long-life designs
PAN India delivery and support
On-site warranty on selected product ranges
Trusted by factories, warehouses, hotels, hospitals, and retail chains

Our products are engineered for continuous operation, durability, and compliance with modern industrial hygiene requirements.

Model Name ACXS1201Y (Aluminium Body-Standard)

Size 4 Feet

Volt 220 V; Single Phase, 50 Hz

Air Volume 2000 CFM (H), 1450 CFM (L)

Assembly 2 Motor 4 Blowers

Power 240 Watts

Air Velocity 18-23 m/s

Noise Level 50 dB

Height Covered 10 Feet

# of Blower 4 Blowers

Motor HP 0.20 HP

Shaft Double Shaft- 2

Phase Single

CMH 3399 CMH(H) ; 2464 CMH(L)

Maintainance Not Required

Core Components Motor

Key Selling Points Long Service Life

Application Keep the Clean Air Indoor

Sensor/Door Switch Available

Flow Type Non Recirculating

Blower Diameter 5 inch

Front Chasis Aluminium

Suction Grills ABS

Mounting Horizontal / Vertical

Motor Type Squirrel Cage Induction Type

Motor Power 120 W- 2 Motor

Weight 10 Kgs

CFM 2000 CFM(H) ; 1450 CFM(L)

Outer Look Elegant Sleek

% Insect/Dust Rejection 92%

Color White

After Warranty Service Online Support / Spare Parts

After-Sales Service Free Spare Parts

Dimension 1200 x 210 x 235

RPM 2800

Motor Winding 100% Copper

Operation Switch- Dual Speed

Fan Type Centrifugal

Voltage 220V/1P/50Hz

Main & Back Plate MS Powder Coated

Blower ABS

Warranty Duration 5 Years Manufacturer Warranty

Shipping Weight 28-32 kg

Shipping Dimensions 1900 x 300 x 250 mm

Lead Time 7-10 Business Days

Installation Requirements Professional Installation Recommended - Requires wall mounting, electrical connection, and proper ventilation setup

Compatibility Information Compatible with commercial and industrial doorways up to specified width. Works with automatic door sensors and manual operation.

Dimensions (Length x Width x Height) 1800-2400 mm (H) x 210-2100 mm (W) x 235 mm (D)

Energy Consumption (Monthly) 8-12 kWh/month (depending on usage)

Customer reviews

5.00

(4,331 Reviews)

5 Stars

100%

4 Stars

3 Stars

2 Stars

1 Star

Add your review

Your email address will not be published. Required fields are marked *

Please login to write review!

4,331 review(s) for "Air Curtain 4 Feet | Aluminium Body | Standard Series | Chronovex"

Frequently Asked Questions

Find answers to common questions about this product

An aluminium body air curtain is a device used to create an invisible barrier of air across the doorway, preventing the exchange of indoor and outdoor air. It features an aluminium body construction, which enhances durability and makes it suitable for various applications.

An aluminium body air curtain operates by blowing a high-velocity stream of air across an entrance or doorway. This air stream forms a barrier that helps to block insects, dust, pollutants, and outside temperatures from entering a controlled environment while maintaining indoor comfort.

Using an aluminium body air curtain offers several advantages, including:Energy savings by reducing heat or cold air lossImproved indoor air quality by preventing dust and pollutants from enteringInsect control by keeping flying insects outsideIncreased comfort for occupants near the doorwayEnhanced durability and longevity due to the aluminium body construction

Aluminium body air curtains are versatile and can be used in various settings, such as:Commercial establishments (stores, restaurants, offices, etc.)Industrial facilities (warehouses, factories, workshops, etc.)Healthcare facilities (hospitals, clinics, laboratories, etc.)Educational institutions (schools, universities, research facilities, etc.)Hospitality industry (hotels, resorts, conference centers, etc.)

Yes, aluminium body air curtains are available in different sizes and can be customized to fit various door widths and heights. It is essential to choose the appropriate size to ensure maximum effectiveness in maintaining the air barrier.

Yes, aluminium body air curtains are designed for easy installation. They can be mounted horizontally above the door or vertically on the side. Most air curtains come with installation instructions, and professional installation assistance is often available.

Modern aluminium body air curtains are designed to operate quietly, providing an efficient air barrier without causing disturbance. Manufacturers prioritize noise reduction to ensure a comfortable and peaceful environment for occupants.

Like any other mechanical device, aluminium body air curtains benefit from regular maintenance. Routine maintenance includes cleaning the filters, inspecting the motor and fan components, and ensuring proper airflow. Manufacturers typically provide maintenance guidelines and recommendations.

Yes, aluminium body air curtains can complement heating and cooling systems. They can help prevent temperature fluctuations caused by the exchange of indoor and outdoor air, thus improving energy efficiency and maintaining a comfortable environment.

Yes, aluminium body air curtains contribute to energy efficiency by reducing the loss of conditioned air through doorways. By creating an air barrier, they help minimize the load on heating and cooling systems, resulting in potential energy savings.
